| MODEL | SM-TD-24 | SM-TD-48 | SM-TD-96 |
|---|---|---|---|
| Loading capacity | 24 Trays | 48 Trays | 96 Trays |
| No of Doors | One | One | Two |
| No of Blowers | One | One | One |
| Motor | 1.0 HP / 1440 RPM / 415 | 1/1 HP / 1440 RPM / 415 | 2/1 HP / 1440 RPM / 415 |
| - 440 V / 50 Hz / 3 Phase | - 440 V / 50 Hz / 3 Phase | - 440 V / 50 Hz / 3 Phase | |
| Electrical Heating Load | 12 kW | 18 kW | 27 kW |
| Tray Loading | Rack System | One Trolley | Two Trolley |
| Tray Size | 812 mm X 406 mm X 31 mm (32 Inch X 16 Inch X 1 ¼ Inch) | ||
| Trolley Dimension | Fixed Racks | 840 mm X 960 mm X 1780 mm | |
| MODEL | SM-TD-12 | SM-TD-6 |
|---|---|---|
| Loading capacity | 12 Trays | 6 Trays |
| No of Doors | One | One |
| No of Blowers | One | One |
| Motor | 0.5 HP/1440 RPM/415-440 V/50 Hz/3 Phase | |
| Electrical Heating Load | 12 kW | 12 kW |
| Tray Loading | Rack System | Rack System |
| Tray Size | 812 mm X 406 mm X31 mm (32 Inch X 16 Inch X 14 Inch) | |
| Trolley Dimension | Fixed Racks | Fixed Racks |
