SAIMACH PHARMATECH PVT. LTD.
Plot No. 1712, Phase 3,
Vatva GIDC, Vatva,
Ahmedabad-382445, Gujarat, India
High Speed Rotary Tablet Press cGMP
| MODEL | SPD I-27 | SPD I-35 | SPD I-35 | SPD I-45 |
|---|---|---|---|---|
| Type of Tooling | D | DB | B | BB |
| * Output Tablets / Hour (Single Layer) | 58,320 to 129,000 | 75,600 to 168,000 | 75,600 to 168,000 | 97,600 to 216,000 |
| Max. Operating Pressure (Main) | 20 mm | 20 mm | 17.5 mm | 17.5 mm |
| Upper Punch Entry | 1.5 to 8 mm | |||
| Main Electric Motor | 3.75 kW/5.0 hp, 1440 RPM, 415V, 3 Phase, 50Hz | |||
| Powder Force Feeder Motor (Optional) | 0.75 kW/1.0 hp , 1440 RPM, 415V, 3 Phase, 50Hz | |||
| Overall dimensions (cm) | 111 x 125 x 181 H | |||
| Case dimensions (cm) | 136 x 150 x 200 H | |||
| Net weight | 1590 kg | |||
| Gross Weight | 1800 kg | |||
Depending upon the Tooling Size & Shape, material characteristics and also ambient condition. NOTE: DUE TO CONTINIOUS IMPROVEMENTS IN THE MACHINERIES, SPECIFICATION/SHAPE OF THE MACHINERIES IS SUBJECT TO CHANGE WITHOUT ANY PRIOR NOTICE.
