| MODEL | SM-MM-200 | SM-MM-50 |
|---|---|---|
| Output | 50 to 200 Kg/Hour | 2 to 10 Kg/Hour |
| Rotor Assembly Diameter | 250 mm.Approx. | 156 mm.Approx. |
| Rotor Speed | 750/1500/2300/3000 RPM | 750/1500 /2300/3000 RPM |
| Beaters | 12 Nos. with knite and impact edges and 2 Nos. scraper blades | |
| Screen dimension | Inner Dim. 265 mm./ Height 140 mrn | Inner Dim. 168 mm./ Height 88 mm |
| Motor | 3.0 HP/1440 RPM/3 Phase | 0.5 HP/1440 RPM/3 Phase |
| Starter | "DOL" with reversible switch | "DOL' with reversible switch |
| Material charging height | 1450 ± 5 mm. | 955 ± 5 mm. |
| Material discharging height | 750 ± 5 mm. | 450 ± 5 mm. |
